1.The Shaft is made of seamless pipe and solid shaft(AISI4140)
2.Cage adopts Flat noddles type use round bar
3. Hammer Material is wear-resistant (NM400) and multiple uses
4. Hammer has a long span of 800 hours
5. The surface of the palm core is adhered to the partial fibers, and the fiber and the core are separated by high-speed rotation.This machine has the function of nut polishing, fiber separation 2 in 1! Strong practicality, low energy consumption, high efficiency!
Item | Model | ||
YHNPS-1 | YHNPS-2 | ||
Capacity FFB ton/hr | 1 | 2 | |
Power kw 380V/3P/50Hz | 4.0 | 5.5 | |
Shaft Speed rpm/min | 300-350 | 300-350 | |
Cage Diameter mm: | 500 | 750 | |
After process Fiber remain % | ≤5 | ≤5 | |
Driver connect Model | Speed reducer+coupling | Speed reducer+coupling | |
Dimension | L（mm） | 1750 | 1750 |
W（mm） | 550 | 800 | |
H（mm） | 1200 | 1500 | |
Weight | kg | 355 | 510 |
